ODS Instance and Tenant Management in Admin App

warning

This is pre-release documentation for software that is not yet available.

This guide covers the creation and management of tenants and Operational Data Store (ODS) instances using the Ed-Fi Admin App. Proper tenant and ODS instance management is essential for multi-tenant Ed-Fi ODS/API implementations.

Understanding ODS Instance and Tenants​

Operational Data Store (ODS) Instances​

The ODS is the central data repository that stores educational data. In multi-tenant scenarios, each tenant typically has its own dedicated ODS instance or shares an ODS with data isolation.

At the database level, a single pairing of EdFi_Admin and EdFi_Security databases can support one more instances of the EdFi_Ods database.

Multi-Tenancy​

tip

Multi-tenancy was introduced in ODS/API 7.1. This section does not apply to prior versions of the ODS/API

For more information, see Single and Multi-Tenant Configuration.

In the Ed-Fi Technology Suite, a tenant represents an isolated environment for a specific organization or group. Each tenant has its own:

  • Data isolation
  • Security boundaries
  • Configuration settings
  • User access controls

These tenants are isolated "virtual environments" that allow users the ability to locally control things like claimsets, vendors, and applications without impacting other tenants hosted in the same environment. At the database level, each tenant has a separate pairing of the EdFi_Admin and EdFi_Security databases, thus isolating the security settings at the tenant level.

The diagram below depicts how an API client is routed to the correct ODS instance:


Notice that the tenant ID that is part of the URL informs how to route API requests through the Ed-Fi API.

Tenant Management​

Like other resources in the Admin App, users must have the appropriate permissions assigned to them to manage Ed-Fi tenants in their Ed-Fi environment(s). With the appropriate permissions, users are able to create and delete tenants from their Ed-Fi environment(s). If you do not see the options to create or delete a tenant within your Ed-Fi environment but believe you should have these permissions, please reach out to your system administrator.

warning

Tenant management is not yet fully functional in the Ed-Fi Admin App. At this time, tenants can only be created during initial environment setup.

If you add additional tenants to a multi-tenant ODS/API 7.x installation after having already created an environment, then start over by creating a new environment.

ODS Instance Management​

An Operational Data Store (ODS) is a database that holds operational data for the current school year in the Ed-Fi API. The data is stored in accordance to Ed-Fi Data Standard. In multi-tenant environments, each tenant can have its own dedicated ODS or share an ODS with other tenants.

Creating and Managing ODS Instances​

  1. Navigate to your environment and select the appropriate tenant.

  2. Within the tenant, locate the ODS section where you can view existing ODS instances.

  3. If you have the appropriate permissions, you'll see an option to create a new ODS instance. Click + New to begin the ODS creation process.

  4. Configure the ODS settings:

    • ODS Name: Provide a descriptive name for the ODS instance
    • Database Configuration: Set up connection parameters and database settings
    • Academic Year: Specify the academic year this ODS will serve
    • Data Standards Version: Select the appropriate Ed-Fi Data Standard version

  5. Review and save your ODS configuration.

tip

When creating multiple ODS instances, consider your data archival strategy and ensure proper naming conventions that reflect the academic year and purpose of each ODS.

ODS Configuration Best Practices​

  • Performance Optimization: Configure appropriate indexing and query optimization settings
  • Backup Strategy: Implement regular backup procedures for data protection
  • Security Settings: Ensure proper access controls and encryption are in place
  • Monitoring: Set up monitoring and alerting for ODS performance and availability

Multi-Tenant Architecture Benefits​

Using the multi-tenant architecture provides several advantages:

  • Data Isolation: Each tenant operates independently with its own data boundaries
  • Scalability: Resources can be allocated based on individual tenant needs
  • Flexibility: Different tenants can have different configurations and permissions
  • Cost Efficiency: Shared infrastructure reduces overall operational costs
  • Simplified Management: Centralized administration with tenant-specific control

Troubleshooting​

Common Tenant Issues​

Tenant Creation Failures​

  • Verify you have administrative permissions for the environment
  • Check that the Tenant ID is unique and follows naming conventions
  • Ensure all required fields are properly filled out
  • Review system logs for specific error messages

ODS Connection Problems​

  • Validate database connection strings and credentials
  • Check network connectivity between the Admin App and database
  • Verify that the database server is running and accessible
  • Review firewall and security group configurations

Permission Issues​

  • Confirm your user account has the necessary tenant management permissions
  • Check with your system administrator about role assignments
  • Verify that you're working within the correct environment scope

Getting Support​

For additional assistance with tenant and ODS management:

  • Review system logs and error messages
  • Review the multi-tenancy implementation guide
  • Contact your system administrator for environment-specific issues
  • Engage with the Ed-Fi Community for best practices and troubleshooting tips

Proper tenant and ODS management ensures secure, scalable, and efficient operation of your Ed-Fi implementation across multiple organizational units or environments.
